PTT MOTOR
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
POWER TRIM AND TILT MOTOR
DISASSEMBLY
Follow the left “Step” for removal.
Power trim and tilt motor ass’y Refer to “TILT CYLINDER, PUMP HOUS-
ING AND MOTOR REMOVAL”.
1 Screw 3
2 Stator 1
3 Armature ass’y 1
4 Plane washer 1
5 O-ring 1 55.8 × 52.0 mm
6 Brush ass’y 1
7 Screw (with washer) 2
8 Lead wire 1
9 Brush ass’y 1
10 Cover plate 1
11 Circuit breaker 1
12 Brush spring 2
13 Base 1
14 Oil seal 1
Reverse the removal steps for installation.
NOTE:
When installing the armature, hold the
armature shaft to prevent the armature
coming off from the base assembly.
To Next Page
