5-11
POWR
E
FLYWHEEL MAGNETO AND MAGNETO BASE
SERVICE POINTS
Flywheel magneto removal
1. Remove:
● Flywheel nut
Å For USA and CANADA
ı Except for USA and CANADA
CAUTION:
The major load should be carried in the
direction of the arrows. If not, the holder
may easily slip off.
Flywheel holder:
YB-06139/90890-06522
Å
ı
2. Remove:
● Flywheel magneto
Å For USA and CANADA
ı Except for USA and CANADA
CAUTION:
● Keep the nut side flush with the crank-
shaft end until the flywheel comes off the
tapered portion of the crankshaft.
● To prevent damage to the engine or
tools, screw in the flywheel magneto-
puller set-bolts evenly and completely so
that the puller plate is parallel to the fly-
wheel.
Universal puller:
YB-06117/90890-06521
Å
ı
