7-22
BRKT
E
SWIVEL BRACKET
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
SWIVEL BRACKET REMOVAL
(Manual tilt)
Follow the left “Step” for removal.
Upper case ass’y Refer to “UPPER CASE REMOVAL”.
Clamp bracket Refer to “CLAMP BRACKET”.
Steering bracket Refer to “STEERING BRACKET”.
1 Tilt lock rod 1 1 Shallow water drive model
2 Tilt lock rod 2 1
3 Rod joint 3
4 Clip 1
5 Tilt lever shaft 1
6 Tilt lever 1, 2* *: Shallow water drive model
7 Tilt lock rod 3 1, 2*
8 Tilt lock rod 4 1
9 Clip 1 *: Shallow water drive model
10 Pin 1
11 Lever 1 1
12 Spring 1
13 Lever 2 1
14 Spring 2
15 Clip 1
16 Tilt lock plate shaft 1
17 Washer 2
18 Spring 1 *: Shallow water drive model
19 Collar 1
20 Tilt lock ass’y 1
21 Shallow water drive lever 1 *: Shallow water drive model
22 Clip 1
23 Cotter pin 2
24 Tilt lock shaft 1
25 Tilt lock plate 1 1
26 Tilt lock arm 1
27 Tilt lock plate 2 1
Reverse the removal steps for installation.
