5-18
POWR
E
REED VALVE AND CHECK VALVE
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
REED VALVE AND CHECK
VALVE REMOVAL
Follow the left “Step” for removal.
Oil tank ass’y Refer to “OIL TANK” in chapter 4.
Carburetor ass’y Refer to “CARBURETOR REMOVAL” in
chapter 4.
1 Clip 3 Oil injection model
2 Oil delivery hose 3
3 Bolt (with washer) 12 6 × 12 mm
4 Neutral switch stay 1 WH, EHTO model
5 Intake manifold ass’y 1
6 Screw (with washer) 6 5 × 14 mm
7 Reed valve ass’y 3
8 Valve plate gasket 2
9 Reed valve plate 1
10 Clip 6 Oil injection model
11 Oil delivery hose 1 1 250 mm
12 Oil delivery hose 2 1 180 mm
13 Oil delivery hose 3 1 90 mm
14 Check valve 3
REED VALVE DISASSEMBLY
1 Screw (with washer) 4
2 Valve stopper 2
3 Reed valve 2
4 Reed valve body 1
Reverse the removal steps for installation.
NOTE:
Tighten the bolts in sequence and in two
steps of torque.
NOTE:
When connecting the hose, feed oil into it
while taking care not to allow air to enter.
