7-20
BRKT
E
STEERING BRACKET
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
STEERING BRACKET REMOVAL Follow the left “Step” for removal.
Upper case ass’y Refer to “UPPER CASE REMOVAL”.
1 Flange bolt 1 Manual tilt model
2 Seal rubber 1
3 Circlip 1
4 Lower mount housing 1
5 Steering bracket 1
6 Plane washer 1
7 Bushing 1
8 O-ring 1
9 Bushing 1
10 Friction piece 1 Manual tilt model
11 Bushing 1
12 O-ring 1
13 Bushing 1
14 Swivel bracket ass’y 1
Reverse the removal steps for installation.
