2-8
SPEC
E
MAINTENANCE SPECIFICATIONS
THERMOSTAT:
Opening temperature ˚C (˚F) 48 ~ 52 (118 ~ 126)
Full-opening temperature ˚C (˚F) 60 (140)
Valve lift mm (in) 3 (0.12)
OIL INJECTION PUMP:
Identification mark 63D00
Specified discharge cm
3
(US
oz, Imp oz)
1.60 ± 0.50 (0.054 ± 0.017, 0.056 ± 0.018)
REED VALVE:
Valve stopper height mm (in) 6.0 ± 0.2 (0.24 ± 0.01)
Valve bending limit mm (in) 0.2 (0.01)
CARBURETOR:
(M model) (E, W model) (M model) (E, W model)
Identification mark 63B00 63D00 62W00 62X00
Float height mm (in) 15.0 ± 1.0 (0.59 ± 0.04)
Valve seat size mm (in) 1.2 (0.05)
Main jet (M.J.) # 115 118(M) 125 130
Main nozzle (M.N.) mm (in) 3.0 (0.12) 3.2 (0.13) 3.0 (0.12)
Main air jet (M.A.J.) # 160 130 140
Pilot jet (P.J.) # 60 62
Pilot air jet (P.A.J.) # 75 90 80
Pilot screw (P.S.) turns out 1-1/2 ± 1/4 1-5/8 ± 1/4 1-3/8 ± 1/4
Starter jet (S.J.) mm (in) — 1.0 (0.04) — 1.0 (0.04)
Electrothermal valve resistance
(color — color)
Ω (color) —
2.32 ~ 3.48
(L — B)
—
2.32 ~ 3.48
(L — B)
Idle speed rpm 800 ± 50
RECOIL STARTER:
Starter rope length mm (in) 2,095 (82.5)
Item Unit
Model
40 hp 50 hp
