MAINTENANCE SPECIFICATIONS
Symbol Unit
Model
Manual tilt Hydro and PTT
B1 mm (in) 62.5 (2.5) 126 (5.0)
B2 mm (in) 208 (8.2) 254 (10.0)
B3 mm (in) 121.5 (4.8) 163.5 (6.4)
B4 mm (in) 32 (1.3) 50.8 (2.0)
B5 mm (in) 131.5 (5.2) 180 (7.1)
B6 mm (in) 245 (9.6) 355 (14.0)
B9 mm (in) 25 (1.0) 18.5 (0.7)
B11 mm (in) 90.5 (3.6) —
B12 mm (in) 57 (2.2) —
B13 mm (in) 122 (4.8) —
B14 mm (in) 156 (6.1) —
D1 mm (in) 10.5 (0.4) 13 (0.5)
D2 mm (in) 26 (1.0) 55.5 (2.2)
C1 mm (in) 30 (1.2) —
C2 mm (in) 66 (2.6) —
C3 mm (in) — 69 (2.7)
