5. Check the entire signaling system's
wiring.
Refer to "CIRCU
IT DIAGRAM" on
page 8-21.
Replace the meter assembly.
The neutral ind
ic at or light fails to come on.
1. Check the gear posi ti on sensor.
Refer to "CHECKING THE GEAR
POSITION SENSOR" on page
8-110.
OK i
2. Check the relay unit (d iode).
Refer to "CHECKING THE RELAY
UNIT (DIODE)" on page 8-99.
OK J.
3. Check the enti re signaling system's
wiring.
Refer to "CIRCUIT DIAGRAM" on
page 8-21.
OK J.
Replace the meter assembly.
The oil level warning light fails to come on.
1. Check the o
il level sw i tc h.
Refer to "CHECKING THE
SWITCHES" on page 8-89.
OK i
2. Check the entire signaling system's
wiring.
Refer to "CIRCU
IT DIAGRAM" on
page 8-21.
OK i
Replace the meter assembly.
The fuel level warning light fails to come on.
1. Check the fuel sender.
Refer to "CHECKING THE FUEL
SENDER" on page 8-104.
OK i
NG
-t
NG -t
NG -t
NG -t
NG -t
NG -t
NG -t
8-25
SIGNALING SYSTEM
Properly connect or repair the signaling
system's wi
ri ng.
Replace the gear position
se nsor.
Replace the relay uni
t.
Properly connect or repair the signaling
system's wiring.
Rep
la ce the oil level switch.
Properly connect
or repair the signaling
syst
em 's wi ri ng.
Replace the fuel pump assembly.
