1. Dimmer switch
2. Pass switch
3. Turn signal
sw itch
4. Horn switch
5. Clutch
sw itch
6. Oil level switch
7. Sidestand switch
8. Ha zard switch
9. Start/engi ne stop switch
10. Drive mode
sw itch
1
1. Front brake li ght switch
1
2. Main sw itch
13. Rear brake light switch
