8.2 Tuning-less Function
8-19
8
Adjustments
(4) Parameters Disabled by Tuning-less Function
When the tuning-less function is enabled in the factory settings, the settings of these parameters are not avail-
able: PnAC2, PnAC4, PnAC6, Pn103, Pn104, Pn105, Pn106, Pn160, Pn139 and Pn408. These gain-related
parameters, however, may become effective depending on the executing conditions of the functions specified
in the following table. For example, if EasyFFT is executed when the tuning-less function is enabled, the set-
tings in PnAC2, Pn104, PnAC4, Pn105, PnAC6, Pn106, and Pn103, as well as the manual gain switch setting,
will be enabled, but the settings in Pn408.3, Pn160.0, and Pn139.0 will be not enabled
.
∗ : Parameter enabled
× : Parameter disabled
8.2.3 Related Parameters
The following parameters are automatically adjusted when the tuning-less function is executed.
After you enable the tuning-less function, do not change the following parameters, e.g., from the SigmaWin+.
Parameters Disabled by Tuning-less Function
Related Functions and
Parameters*
Item Pn Number
Pn
Number
Mechani
cal
Analysis
(Vertical
Axis
Mode)
Easy
FFT
Mechanical
Analysis
(Vertical
Axis Mode)
Gain
Speed Loop Gain
2nd Speed Loop Gain
PnAC2
Pn104
 
Speed Loop Integral Time Constant
2nd Speed Loop Integral Time Constant
PnAC4
Pn105
×

Position Loop Gain
2nd Position Loop Gain
PnAC6
Pn106
×

Moment of Inertia Ratio Pn103  
Advanced
Control
Friction Compensation Function Selec-
tion
Pn408.3
×× ×
Anti-resonance Control Adjustment
Selection
Pn160.0
×× ×
Gain
Switching
Gain Switching Selection Switch Pn139.0
×× ×
Parameter Name
Pn401 Torque Reference Filter Time Constant
Pn40C 2nd Notch Filter Frequency
Pn40D 2nd Notch Filter Q Value
