YASKAWA E-V-MD Series User Manual

3 Specifications and Dimensional Drawings
3.2.4 Dimensional Drawings
3-18
3.2.4 Dimensional Drawings
This section provides dimensional drawings.
Dimensions in the dimensional drawings are in millimeters.
(1) Type A01 SERVOPACK
 Board with Four Axes
• Without Mounting Option
• With Mounting Option
170
5 100 60
5 68 92
113
5103
9 16.6
30.5
Six studs
(M3 female threads,
effective screw depth: 4 mm)
Four, n5 (M4 mounting holes)
210 200
50
1035
5
(
20
)
170
(
20
)
1.5
123
18612
