10.2 Alarm Displays
10-3
10
Maintenance, Inspections, and Troubleshooting
10.2 Alarm Displays
The following sections describe troubleshooting in response to alarm displays.
The alarm name, alarm meaning, alarm stopping method, and alarm reset capability are listed in order of the
alarm numbers in 10.2.1 List of Alarms.
The causes of alarms and troubleshooting methods are provided in 10.2.2 Troubleshooting of Alarms.
10.2.1 List of Alarms
This section provides list of alarms.
Servomotor Stopping Method
If an alarm occurs, the servomotor can be stopped by doing either of the following operations.
Gr.1: The servomotor coasts to a stop when an alarm occurs.
Gr.2: The servomotor is stopped according to the setting in Pn00B.1 if an alarm occurs. Pn00B.1 is factory-set
to stop the servomotor by setting the speed reference to
"
0.
"
The servomotor under torque control will
always use the Gr.1 method to stop. By setting Pn00B.1 to 1, the servomotor stops using the same
method as Gr.1. When coordinating a number of servomotors, use this stopping method to prevent
machine damage that may result due to differences in the stop method.
Alarm Reset
Available: Removing the cause of alarm and then executing the alarm reset can clear the alarm.
N/A: Executing the alarm reset cannot clear the alarm.
Alarm
Number
Alarm Name Meaning
Servo-
motor
Stopping
Method
Alarm
Reset
A.020 Parameter error 1
The parameter data in the SERVOPACK is
incorrect.
Gr.1 N/A
A.021 Parameter error 2
The parameter data in the SERVOPACK is
incorrect.
Gr.1 N/A
A.022 Parameter error 3
The parameter data in the SERVOPACK is
incorrect.
Gr.1 N/A
A.023 Parameter error 4
The parameter data in the SERVOPACK is
incorrect.
Gr.1 N/A
A.030 Main Circuit Detector Error Detection data for main circuit is incorrect. Gr.1 Available
A.040 Parameter Setting Error 1
The parameter setting is outside the setting
range.
Gr.1 N/A
A.042 Parameter Combination Error
Combination of some parameters exceeds the
setting range.
Gr.1 N/A
A.050 Combination Error
The SERVOPACK and the servomotor capaci-
ties do not match each other.
Gr.1 Available
A.051 Unsupported Device Alarm The device unsupported was connected. Gr.1 N/A
A.0b0
Cancelled Servo ON
Command Alarm
The servo ON command (SV_ON) was sent
from the host controller after executing a utility
function that turns ON servomotor.
Gr.1 Available
A.100
Overcurrent or Heat Sink
Overheated
An overcurrent flowed through the IGBT. Gr.1 N/A
A.400 Overvoltage Main circuit DC voltage is excessively high. Gr.1 Available
A.510 Overspeed
The servomotor speed is above the maximum
rotational speed.
Gr.1 Available
A.520 Vibration Alarm
Incorrect vibration at the motor speed was
detected.
Gr.1 Available
To Next Page
