YASKAWA E-V-MD Series User Manual

3 Specifications and Dimensional Drawings
3.1.2 Dimensional Drawings
3-6
3.1.2 Dimensional Drawings
This section provides dimensional drawings of the servomotors.
Dimensions in the dimensional drawings are in millimeters.
(1) 3.3 to 11 W
<Shaft End>
With a Flat Seat
Model
SGMMV–
L L1 L2
Approx. Mass
[kg]
B3E2A1 58 48 21.3 0.055
B5E2A1 64 54 27.3 0.06
B9E2A1 98 88 61.4 0.1
12
34
2.5
15
16±0.1 Dia.
1026.7
L1
L2
15
12.5
3.6
45°
20
3.7
L
0.02
A
0.04 Dia.
A
0.04 A
2-M2 Tapped Holes, Depth 3
Protective Tube, 4 Dia.
300±15
300±15
Encoder Cable, 4 Dia.
UL20276
Pin No.1
Pin No.5
Pin No.2
Pin No.6
Plug: 55102-0600
(Molex Japan Co., Ltd.)
Receptacle: 43025-0400
(Molex Japan Co., Ltd.)
Motor Lead
AWG26,UL10095
or UL3266
4 Dia.
0
- 0.008
11 Dia.
0
- 0.018
A
0.02
6
0.5
3.5
4 dia.
0
- 0.008
11 Dia.
0
- 0.018
4 dia.
0
- 0.008
