YASKAWA E-V-MD Series User Manual

3.1 Servomotors
3-7
3
Specifications and Dimensional Drawings
(2) 10 to 30 W
 Servomotors without Holding Brakes
<Shaft End>
Servomotors with a Flat Seat
Model
SGMMV–
L L1 L2
Approx. Mass
[kg]
A12A1 70 54 27.5 0.13
A22A1 80 64 37.5 0.17
A32A1 90 74 47.5 0.21
12
34
300 ±30
Receptacle: 43025-0400
(Molex Japan Co., Ltd.)
Pin No.2Pin No.1
Pin No.6Pin No.5
Plug: 55102-0600
(Molex Japan Co., Ltd.)
Encoder Cable, 4 Dia.
UL20276
Protective Tube
5 Dia., Black
Motor Lead
AWG24,UL10095
or UL3266
±30300
28 Dia.
□25
16
45°
2.5
16
26.5
12
L2
L
L1
2-M3 Tapped
0.04 Dia.
A
A
0.02
0.04
A
4
5 dia.
0
- 0.008
20 Dia.
0
- 0.021
A
0.02
10
0.5

5 Dia.
0
- 0.008
20 Dia.
0
- 0.021
