11 Appendix
11.2.1 List of Parameters
11-16
Pn594
2
Input Signal Selection
(/EXT2 Signal Assignment)
0000 to
2007
− 0000 After restart Setup −−
Pn595
2
Input Signal Selection
(/EXT3 Signal Assignment)
0000 to
2007
− 0000 After restart Setup −−
(cont’d)
Parameter
No.
Size Name
Setting
Range
Units
Factory
Setting
When
Enabled
Classification Profile
Reference
Section
/EXT2 Signal Pin Number Assignment
0 Selects sequence input signal /SI-0.
1 Selects sequence input signal /SI-1.
2 Selects sequence input signal /SI-2.
3 Selects sequence input signal /SI-3.
4 Selects sequence input signal /SI-4.
5 Selects sequence input signal /SI-5.
6 Selects sequence input signal /SI-6.
7 Selects sequence input signal /SI-7.
Reserved (Do not change.)
Reserved (Do not change.)
/EXT2 Signal Assignment Selection
0 /EXT2 signal assignment disabled. [factory setting]
1 /EXT2 signal assigned. Signal is ON for low level.
2 /EXT2 signal assigned. Signal is ON for high level.
4th 3rd 2nd 1st
digit digit digit digit
n.
/EXT3 Signal Pin Number Assignment
0 Selects sequence input signal /SI-0.
1 Selects sequence input signal /SI-1.
2 Selects sequence input signal /SI-2.
3 Selects sequence input signal /SI-3.
4 Selects sequence input signal /SI-4.
5 Selects sequence input signal /SI-5.
6 Selects sequence input signal /SI-6.
7 Selects sequence input signal /SI-7.
Reserved (Do not change.)
Reserved (Do not change.)
/EXT3 Signal Assignment Selection
0 /EXT3 signal assignment disabled. [factory setting]
1 /EXT3 signal assigned. Signal is ON for low level.
2 /EXT3 signal assigned. Signal is ON for high level.
4th 3rd 2nd 1st
digit digit digit digit
n.
