YASKAWA E-V-MD Series User Manual

5 Wiring and Connections
5.1.2 Main Circuit and Control Power Supply Cables
5-6
(2) Control Power Supply Cable Specifications
The control power supply cable specifications are given below.
 Control Power Supply Connector (CN31)
 Parts and Functions of the Control Power Supply Connector (CN3)
 Power Supply Capacity and Wire Size
• Type A01 SERVOPACK
• Type A02 SERVOPACK
Connector Housing Contacts Manufacturer
Control power supply
connector
Cable side: VHR-3N,
Type A01 SERVOPACK side:
B3PS-VH,
Type A02 SERVOPACK side:
B3P-VH
SVH-41T-P1.1 J.S.T. Mfg. Co., Ltd.
Ter mi nals Signal Name Specification
1 L1C Control power supply input terminal +
24 VDC ±15%
2 L2C Control power supply input terminal -
3 FG Ground terminal –
SERVOPACK Model Power Supply Capacity Power Supply Cable Wires
SGDV-MDA01E4M3A (4 axes) 1.6 A min
AWG16 to AWG20SGDV-MDA01E8M3A (8 axes) 1.7 A min
SGDV-MDA01ECM3A (12 axes) 1.9 A min
Current Capacity [A] Power Supply Cable Wires
2.0 A AWG16 to AWG20
