5.3 I/O Signal Assignments
5-17
(2) Input Signal Pin Assignments
Use parameters Pn590 to Pn595 to assign I/O signal connector pins 5 and 7 to 13.
(3) Output Signal Function Assignments
The following table gives the setting of the Pn596 parameter.
(4) Output Signal Pin Assignments
The assignments for the /BK-0 to /BK-7 sequence output signals are set with the Pn596 parameter.
Parameter Meaning Pin No. When Enabled Classification
Pn590 to
Pn595
n.0 Selects sequence input signal /SI-0. 5 After restart Setup
n.1 Selects sequence input signal /SI-1. 7 After restart Setup
n.2 Selects sequence input signal /SI-2. 8 After restart Setup
n.3 Selects sequence input signal /SI-3. 9 After restart Setup
n.4 Selects sequence input signal /SI-4. 10 After restart Setup
n.5 Selects sequence input signal /SI-5. 11 After restart Setup
n.6 Selects sequence input signal /SI-6. 12 After restart Setup
n.7 Selects sequence input signal /SI-7. 13 After restart Setup
Parameter Meaning When Enabled Classification
Pn596
n.0
[factory setting]
/BK signal assignment disabled.
After restart Setup
n.1 /BK signal assignment enabled.
Parameter Meaning Pin No. When Enabled Classification
Pn596
n.0 Selects sequence input signal /SO-0. 1-2
After restart Setup
n.1 Selects sequence input signal /SO-1. 3-4
n.2 Selects sequence input signal /SO-2. 14-15
n.3 Selects sequence input signal /SO-3. 17-18
n.4 Selects sequence input signal /SO-4. 19-20
n.5 Selects sequence input signal /SO-5. 21-22
n.6 Selects sequence input signal /SO-6. 23-24
n.7 Selects sequence input signal /SO-7. 25-26
