5.3 Monitoring Machine Operation
5.3.4 XY Trace
5-67
The following dialog box will be displayed.
No. Item Description
Trace Manager This button displays up to 16 points of trace data in a graph.
XY Trace
This button displays the position data of two orthogonal axes in a 2-
dimensional graph.
Open This button starts the selected type of trace.
Cancel
This button returns you to the main window without starting the selected
trace type.
