3.6 Device-specific Settings
3.6.1 Data That Is Automatically Updated during Self Configuration
3-21
3
Machine Controller Setup
Status Display Contents
The items displayed in the Status Column are listed below.
Function Module Status
The following status is displayed for Function Modules.
Precautions When Setting the Parameters
• Always save all settings to the flash memory after changing them.
• When changing the settings, be careful not to set register numbers that overlap with other
Modules.
• Set I/O start and end registers even if a I/O Module is not connected to the MECHATROLINK
network.
Display Description
−−−− The Function Module is not defined.
Empty The Function Module is defined, but it is not operating correctly.
Driving The Function Module is operating normally.
Failure An error was detected in the Function Module.
×
A Function Module is operating, but it is not the Function Module that was
defined.
Initializing
The Function Module is defined, but there is no Detailed Function Module Defini-
tion.
Driving Stop The CPU Unit is stopped (The user programs are stopped).
To Next Page
