B.6 Defaults by Drive Model Selection (o2-04)
B.6 Defaults by Drive Model Selection (o2-04)
Table B.5 Single-Phase, 200 V Class Drives Default Settings by Drive Model Selection
No. Description Unit Default Settings
− Model CIMR-TC − BV0001 BV0002 BV0003
C6-01 Duty Mode Selection −
HD ND HD ND HD ND
0 1 0 1 0 1
o2-04 Drive Model Selection Hex. 30 31 32
E2-11
(E4-11,
T1-02)
Motor rated power kW 0.1 0.2 0.2 0.4 0.4 0.75
b3-06
Output Current 1 during Speed
Search
− 111111
b8-04 Energy Saving Coefficient Value − 481.7 356.9 356.9 288.2 288.2 223.7
C6-02 Carrier Frequency Selection − 414141
E2-01
(E4-01, T1-04)
Motor Rated Current A 0.6 1.1 1.1 1.9 1.9 3.3
E2-02
(E4-02)
Motor Rated Slip Hz 2.5 2.6 2.6 2.9 2.9 2.5
E2-03
(E4-03)
Motor No-Load Current A 0.4 0.8 0.8 1.2 1.2 1.8
E2-05
(E4-05)
Motor Line-to-Line Resistance Ω 35.98 20.56 20.56 9.842 9.842 5.156
E2-06
(E4-06)
Motor Leakage Inductance % 21.6 20.1 20.1 18.2 18.2 13.8
E2-10
(E4-10)
Motor Iron Loss for Torque
Compensation
W 6 11 11 14 14 26
E5-01 PM Motor Code Selection hex FFFF FFFF FFFF FFFF 0002 0002
L2-02
Momentary Power Loss Ride-Thru
Time
s 0.1 0.1 0.1 0.1 0.1 0.1
L2-03
Momentary Power Loss Minimum
Baseblock Time
s 0.2 0.2 0.2 0.2 0.2 0.3
L2-04
Momentary Power Loss Voltage
Recovery Ramp Time
s 0.3 0.3 0.3 0.3 0.3 0.3
L2-05 Undervoltage Detection Level (Uv1) V dc 160 160 160 160 160 160
L8-02 Overheat Alarm Level °C 115 115 115 115 110 110
L8-09
Output Ground Fault Detection
Selection
− 000000
L8-35 Installation Method Selection − 000000
L8-38
Carrier Frequency Reduction
Selection
− 111111
n1-03 Hunting Prevention Time Constant ms 10 10 10 10 10 10
n9-12 On-Delay Compensation Time ms 2.50 2.50 2.50 2.50 2.50 2.50
S6-01 DC Bus Capacity μF 220 220 330 330 610 610
S6-02 Motor Acceleration Time s 1.78 1.78 1.78 1.78 1.78 1.42
