B.6 Defaults by Drive Model Selection (o2-04)
YASKAWA ELECTRIC SIEP C710606 44B YASKAWA AC Drive T1000V Technical Manual 367
Parameter List
B
No. Description Unit Default Settings
Model CIMR-TC BV0006 BV0010 BV0012
C6-01 Duty Mode Selection
HD ND HD ND HD ND
0 1 0 1 0 1
o2-04 Drive Model Selection Hex. 33 34 35
E2-11
(E4-11,
T1-02)
Motor rated power kW 0.75 1.1 1.5 2.2 2.2 3.0
b3-06
Output Current 1 during Speed
Search
0.5 0.5 0.5 0.5 0.5 0.5
b8-04 Energy Saving Coefficient Value 223.7 169.4 169.4 156.8 156.8 136.4
C6-02 Carrier Frequency Selection 413131
E2-01
(E4-01, T1-04)
Motor Rated Current A 3.3 6.2 6.2 8.5 8.5 11.4
E2-02
(E4-02)
Motor Rated Slip Hz 2.5 2.6 2.6 2.9 2.9 2.7
E2-03
(E4-03)
Motor No-Load Current A 1.8 2.8 2.8 3 3 3.7
E2-05
(E4-05)
Motor Line-to-Line Resistance Ω 5.156 1.997 1.997 1.601 1.601 1.034
E2-06
(E4-06)
Motor Leakage Inductance % 13.8 18.5 18.5 18.4 18.4 19
E2-10
(E4-10)
Motor Iron Loss for Torque
Compensation
W265353777791
E5-01 PM Motor Code Selection hex 0003 0003 0005 0005 0006 0006
L2-02
Momentary Power Loss Ride-Thru
Time
s 0.2 0.2 0.3 0.3 0.5 0.5
L2-03
Momentary Power Loss Minimum
Baseblock Time
s 0.3 0.4 0.4 0.5 0.5 0.5
L2-04
Momentary Power Loss Voltage
Recovery Ramp Time
s 0.3 0.3 0.3 0.3 0.3 0.3
L2-05 Undervoltage Detection Level (Uv1) V dc 160 160 160 160 160 160
L8-02 Overheat Alarm Level °C 105 105 100 100 95 95
L8-09
Output Ground Fault Detection
Selection
000000
L8-35 Installation Method Selection 000000
L8-38
Carrier Frequency Reduction
Selection
111111
n1-03 Hunting Prevention Time Constant ms 10 10 10 10 10 10
n9-12 On-Delay Compensation Time ms 1.80 1.80 1.80 1.80 1.80 1.80
S6-01 DC Bus Capacity μF 1400 1400 1850 1850 2400 2400
S6-02 Motor Acceleration Time s 1.42 1.42 1.66 1.45 1.45 1.45
