Zero Adjustment Function (*2):
By using the parameter setting, zero adjustment is
carriedouttoensurethattheoutputforzeroowis
0%. Zero adjustment should be carried out only when
theowtubeislledwithmeasurementuidandthe
owiscompletelystoppedbyclosingthevalves.
During zero adjustment (450 seconds), the current
output is 10.4 mA.
 Flowtubes
Size of AXR Flowtubes:
Lay length code 1 Unit: mm (in.)
Use
Process
Connection
Integral Flowmeter
General-purpose
Use/Explosion
Proof Type
Wafer
*1
80 (3.0), 100 (4.0),
150 (6.0), 200 (8.0)
Flange
*1
25 (1.0), 40 (1.5),
50 (2.0), 65 (2.5),
80 (3.0), 100 (4.0),
150 (6.0), 200 (8.0)
*1: The dimensions of lay length code 1 are the same as
those of the PFA lining standard lay length (lay length
code1)intheAXFseries.Fordetails,read“EXTERNAL
DIMENSIONS.”
Lay length code 2 Unit: mm (in.)
Use
Process
Connection
Integral Flowmeter
General-purpose
Use/Explosion
Proof Type
Wafer
*2
25 (1.0), 40 (1.5),
50 (2.0), 65 (2.5),
80 (3.0), 100 (4.0),
150 (6.0), 200 (8.0)
*2: Excluding the size of 65 mm, dimensions of lay length
code 2 are the same as those of PFA lining replacement
models(laylengthcode2)inAXFseries.Laylengthsfor
special gaskets (optional codes GA, GB, GD) are different.
Fordetails,read“EXTERNALDIMENSIONS.”
Coating:
General-purposeUse/ExplosionProofType:
Size 25 to 100 mm (1 to 4 in.) (Wafer type),
Size 25 to 100 mm (1 to 4 in.) (Flange type):
•Housing: No coating (Stainless steel surface)
•Flange (Flange type only):
No coating (Stainless steel surface)
Size 150 to 200 mm (6.0 to 8 in.) (Wafer type),
Size 150 to 200 mm (6.0 to 8 in.) (Flange type):
•Housing,Flange(Flangetypeonly)
Corrosion-resistant coating
Coating color; Mint green (Munsell 5.6 BG
3.3/2.9 or its equivalent)
Flowtube Material:
Size 25 to 100 mm (1 to 4 in.)
Part Name Material
Housing
Stainless steel-JIS
SUS304
(AISI 304 SS/EN 1.4301
equivalent)
Flange
Stainless steel-JIS
SUS304 or SUSF304
(AISI 304 SS/EN 1.4301
equivalent)
Mini-
Flange
Wafer
type
Size 25 mm
(1.0 in.)
Stainless steel-
SCS13
Size 40 to 100 mm
(1.5 to 4.0 in.)
Stainless steel-JIS
SUS430
ASTM 4300/DIN
X6Cr17/EN1.4016
equivalent
Pipe
Wafer
type
Size 25 mm
(1.0 in.)
Stainless steel-
SCS13
Size 40 to 100 mm
(1.5 to 4.0 in.)
Stainless steel-JIS
SUS304
(AISI 304 SS/EN 1.4301
equivalent)
Flange
type
Size 25 mm
(1.0 in.)
Stainless steel-
SCS13
Size 40 to 100 mm
(1.5 to 4.0 in.)
Stainless steel-JIS
SUS304
( AISI 304 SS/
EN 1.4301 equivalent )
Size 150 mm (6.0 in.) to 200 mm (8.0 in.)
Part Name Material
Housing
Carbon steel-JIS SPCC
equivalent
Flange
Process Connection code: B**
Stainless steel-JIS
SUS304 or SUSF304
(AISI 304 SS/EN 1.4301
equivalent)
Process Connection code: C**
Carbon steel-JIS SS400
or SFVC 2A
Mini-
Flange
Wafer Type
Carbon steel-JIS SS400
or SFVC 2A
Pipe Flange Type/Wafer Type
Stainless steel-JIS SUS
304 (AISI 304 SS/EN
1.4301 equivalent)
Wetted Part Material:
Lining;
Fluorocarbon PFA
*1
lining
*1: PFA is FDA (U.S. Food and Drug Administration)
approval material.
 TheinnersurfaceofthePFAliningismirror-nishedto
Raof0.05to0.15μm.ThevalueofRaistheaverage
ofmeasurementsatseveralpoints.Mirrornished
PFA lining is standard for size 25 to 100 mm (1 to 4
in.) and optional for size 150 to 200 mm (6 to 8 in.)
speciedbyoptionalcodePM.
Electrode;
Stainless steel-JIS SUS316L (AISI 316L SS/EN
1.4404 equivalent), HASTELLOY C-276
*1
equiva-
lent, Tantalum, Platinum-Iridium
