YOKOGAWA ADMAG AXR User Manual

12-7
IM 01E30D01-01EN
<12. OUTLINE>
Accuracy for Multi-drop of HART
(generally accepted values)
Vs: Span setting value (m/s)
Size in mm (in.) Spaninm/s(ft/s) Accuracy
25 to 200
(1 to 8)
0.3≤Vs<1
(1≤Vs<3.3)
±(0.4+0.3/Vs)% of span
1≤Vs<2
(3.3≤Vs<6.7)
± 0.5% of span
2≤Vs≤10
(6.7≤Vs≤33)
± 0.25% of span
(at indications less
than 50% of span)
± 0.5% of rate
(at indications 50% or
more of span)
Repeatability (Reference):
±0.2% of rate
(Whentheowvelocityis1.5m/stoward2m/sof
setting span)
Insulation Resistance:
Inspection location Terminal Test voltage Standard
Power Supply/Digital
Output - Functional
Grounding
SUPPLY/DO
500 V DC
100MΩ
or more
When the optional code A is selected (with the lightning protec-
tor), values are as follows.
Power Supply/Digital
Output - Functional
Grounding
SUPPLY/DO
100 V DC
20MΩ
or more
Note: Conduct the test according to the instruction manual.
Dielectric Strength:
Inspection location Terminal
Test
voltage
Test
time
Standard
Power Supply/Digital
Output - Functional
Grounding
SUPPLY/DO
500 V
AC
1
min.
25 mA
or less
When the optional code A is selected (with the lightning protec-
tor), values are as follows.
Power Supply/Digital
Output - Functional
Grounding
SUPPLY/DO
100 V
AC
1
min.
6 mA
or less
Note: Conduct the test according to the instruction manual.
CE Marking:
CEmarkingisafxedonthenameplateexceptfor
modelswithanyofthefollowingspecications.
•OptionalCode:FF1,CF1,SF2,JF3
Safety Requirement Standards:
CAN/CSA C22.2 No. 61010-1-04
•Altitudeofinstallationsite:Max.2000mabovesea
level
•Installationcategory:I
“Overvoltage category (Installation category)”
describesanumberwhichdenesatransient
overvoltage condition. It implies the regulation for
impulse withstand voltage. “ I ” applies to electrical
equipment which is supplied from the circuit when
appropriate transient overvoltage control means
(interfaces) are provided.
•Pollutiondegree:2
“Pollution degree” describes the degree to which a sol-
id, liquid, or gas which deteriorates dielectric strength
or surface resistivity is adhering. “ 2 ” applies to normal
indoor atmosphere. Normally, only non-conductive
pollution occurs. Occasionally, however, temporary
conductivity caused by condensation must be expect-
ed.
•Indoor/Outdooruse
EMC Conformity Standards:
EN61326-1 Class A, Table 2 (For use in industrial
locations)
EN61326-2-3
•PerformanceSpecicationduringimmunitytest
Flowrateoutput:Outputuctuationwithin±3%of
default (1m/s) span
CAUTION
This instrument is a class A product, and it is de-
signed for use in the industrial environment.
Please use this instrument in the industrial environ-
ment only.
SILCertication:
AXRseriesarecertiedbyexidaincompliancewith
the following standards;
IEC 61508: 2010; Part1 to Part7
Functional Safety of Electrical/electronic/programma-
ble electronic safety-related systems; SIL 2 capability
forsingleowmeteruse,SIL3capabilityfordual
owmeteruse.
