YOKOGAWA ADMAG AXR User Manual

12-14
IM 01E30D01-01EN
<12. OUTLINE>
Item Specications
Applicable
Model
Code
General
Explosion
proof
AXR***G
AXR***C
Bolts, Nuts, and
Gaskets (*2)
Bolts, nuts, and gaskets
are provided for wafer
connections. Available
only for ANSI 150,
JIS10K, or, JIS20K
wafer connections.
Bolts: JIS SUS304 (AISI 304 SS stainless steel equivalent);
Nuts: JIS SUS304 (AISI 304 SS stainless steel equivalent)
Gaskets: Chloroprene rubber (*3)
○ ○
BSC
Bolts: JIS SUS304 (AISI 304 SS stainless steel equivalent);
Nuts: JIS SUS304 (AISI 304 SS stainless steel equivalent)
Gaskets: PTFE-sheathed non-asbestos (*4)
○ ○
BSF
Special Gaskets
(*5)
Viton® gaskets for use with PVC piping.
AllowabletemperatureandpressureareequivalenttoValqua#4010,specialuor-
orubber not mixed.
○ ○
GA
Acid-resistant Viton® gaskets for use with PVC piping.
AllowabletemperatureandpressureareequivalenttoValqua#4010,specialuor-
orubber mixed (mixing #D2470).
○ ○
GC
Alkali-resistant Viton® gaskets for use with PVC piping.
Allowable temperature and pressure are equivalent to Valqua #4010, special
uororubbermixed(mixing#D0970).
○ ○
GD
Oil-prohibited
Use
Electrodes, linings, and grounding rings are assembled and packed with polyethyl-
ene after being cleaned with water and acetone and dried with air.
Thelabel‘OILFREE’isafxed.
○ ○
K1
Oil-prohibited
Use with
Dehydrating
Treatment
Electrodes, linings, and grounding rings are assembled and packed with polyethyl-
ene including desiccants after being cleaned with water and acetone and dried with
air.
Thelabel‘OIL&WATERFREE’isafxed.
○ ○
K5
Epoxy Resin
Coating
Epoxy resin coating which has alkali-resistance instead of standard polyurethane
resin coating. The color is same as standard type.
○ ○
X1
High Anti-corro-
sion Coating
Three-layer coating (polyurethane coating on two-layer epoxy resin coating) in the
same range as that for the standard coating. The color is same as standard type.
Salt/alkali/acid/weather-resistance.
○ ○
X2
Material
Certicate
Reproducedmaterialcerticatesforpipe,electrodes,groundingrings/grounding
electrodes,angesorminianges.
○ ○
M01
Hydrostatic Test
Thetestveriestheabsenceofleaksbyapplyingthefollowingwaterpressures
(which are determined under process connection conditions) to linings for ten min-
utes.Testresultsaredescribedinatestcerticate(QIC).
Process Connection: Water Pressure:
ANSI Class 150, DIN PN10, JIS 10K 1.5 MPa
ANSI Class 300, DIN PN16, JIS 20K 3.0 MPa
DIN PN40 6.0 MPa
JIS F12 1.25 MPa
○ ○
T01
Calibration Cer-
ticate
Level 2: The Declaration and the Calibration Equipment List are issued.
○ ○
L2
Level 3: The Declaration and the Primary Standard List are issued.
○ ○
L3
Level 4: The Declaration and the Yokogawa Measuring Instruments Control System
are issued.
○ ○
L4
Vent Hole
Withaventholeprovidedforpermeableuids(suchasnitricacid,hydrouoricacid,
or sodium hydroxide at high temperature).
Availableonlyforaangetypetube.
○ ○
H
