YOKOGAWA ADMAG AXR User Manual

<6. PARAMETER DESCRIPTION>
6-18
IM 01E30D01-01EN
[B30: Total Unit] Setting of units for totalization
scale
→ThissettingislinkedwiththatofparameterD10.
Thisparameterselectstheowrateunitsforusein
totalization.
Item Description
n Unit/P 10
-9
 FU
u Unit/P 10
-6
 FU
m Unit/P 10
-3
 FU
Unit/P FU
k Unit/P 10
3
 FU
M Unit/P 10
6
 FU
Pulse/s Number of pulses to be counted for one second
at 100% output.
FU: Flow rate unit selected in B21/C40: Base Flow Unit.
[B31: Total Scale] Setting of the totalization scale
→ThissettingislinkedwiththatofparameterD11.
Theowrateistotalizedinindividualcountsin
accordance with this parameter’s setting. If 0 is
selected, it indicates that the totalization function is
not to be used.
NOTE
Ifatotalizationscaleisspecieduponordering,
this parameter is set up before shipment;
however, if this is not the case, it will be
necessary for the appropriate value to be set up
by the user.
NOTE
• Bysettingthetotalizationscale,the
totalized value is displayed on the display
unit. The totalization scale is determined in
accordance with the settings of B30/D10:
Total Unit andB31/D11:TotalScale.
• Themaximumvaluethatcanbedisplayedis
99999999, and if this is exceeded, the value
0 is counted once again. However, counting
stops at 99999999 when the totalization
switch function is used.
• Ifmultiplerangesarebeingused,theow
rate span for the smallest range becomes
the standard for the D13: Total Low Cut
setting value.
• Totalizationforthereverseowrateandfor
thedifferentialowrateiscarriedoutonly
when “Fwd/Rev Ranges” is selected for F10:
DO Function.
• Thetotalizedunitsareindicatedonthe
display unit when B31/D11 is 0.00001,
0.0001, 0.001, 0.01, 0.1, 1, 10, 100, 1000,
or 10000. In the case of other setting values,
the totalized units are not indicated.
Example 1: To count in 1 Ml (mega-liter) steps
withowratespan=1000m
3
/h
Since1Ml=10
3
x m
3
, k Unit/P is set
for B30/D10, and 1 is set for B31/
D11. “x10
3
m
3
” is indicated for the
totalized units in the Display Mode.
Example2:Tocountin10l(liter)stepswithow
ratespan=100m
3
/h
Since1l=10
-3
x m
3
, m Unit/P is set
for B30/D10, and 10 is set for B31/
D11. “x10
-2
m
3
” is indicated for the
totalized units in the Display Mode.
Example3:Tocountin5l(liter)stepswithow
ratespan=100m
3
/h
Since1l=10
-3
x m
3
, m Unit/P is set
for B30/D10, and 5 is set for B31/
D11. Since B31/D11 is not 0.00001,
0.0001, 0.001, 0.01, 0.1, 1, 10, 100,
1000, or 10000, there is no indication
of totalized units in the Display Mode.
• Settingoftotalizationscaleisnotpossible
whenspecicselectionshavebeenmade
for B30/D10:TotalUnit,B31/D11:Total
Scale, and B23/C42:FlowSpan. In such
a case, a setting alarm will be displayed,
and parameters should be changed in
accordance with the instructions given.
[B32: Pulse Unit] Setting of the pulse units
→ This setting is linked with that of parameter E10.
Thisparameterselectstheowrateunitstobe
used for pulse output.
Item Description
n Unit/P 10
-9
 FU
u Unit/P 10
-6
 FU
m Unit/P 10
-3
 FU
Unit/P FU
k Unit/P 10
3
 FU
M Unit/P 10
6
 FU
Pulse/s Number of pulses to be output for one second at
100% output.
FU: Flow rate unit selected in B21/C40: Base Flow Unit.
