<6. PARAMETER DESCRIPTION>
6-19
IM 01E30D01-01EN
[B33: Pulse Scale] Setting of pulse scale
→ This setting is linked with that of parameter E11.
Pulse output is performed in individual counts in
accordance with this parameter’s setting. If 0 is set,
it indicates that the pulse output function is not to be
used.
NOTE
Ifapulsescaleisspecieduponordering,this
parameter is setup before shipment; however,
if this is not the case, it will be necessary for the
appropriate value to be setup by the user.
NOTE
• Bysettingthepulsescale,pulseoutput
performs. The pulse scale is determined in
accordance with the settings of B32/E10:
Pulse Unit and B33/E11:PulseScale.
• Settingofpulsescaleisnotpossiblewhen
specicselectionshavebeenmadefor
B32/E10:PulseUnit,B33/E11:Pulse
Scale, E12: Pulse Width andB23/C42:
Flow Span. In such a case, a setting alarm
will be displayed, and parameters should be
changed in accordance with the instructions
given.
Example 1: To perform pulse output in 1 Ml
(mega-liter)stepswithowratespan
=1000m
3
/h
Since1Ml=10
3
x m
3
, k Unit/P is set
for B32/E10, and 1 is set for B33/
E11.
Example 2: To perform pulse output in 10 l (liter)
stepswithowratespan=100m
3
/h
Since1l=10
-3
x m
3
, m Unit/P is
set for B32/E10, and 10 is set for
B33/E11.
Example 3: To perform pulse output in 5 l (liter)
stepswithowratespan=100m
3
/h
Since1l=10
-3
x m
3
, m Unit/P is set
for B32/E10, and 5 is set for B33/
E11.
[B40: Display Select1]Settingoftherstlinefor
display unit
→ This setting is linked with that of parameter H10.
This parameter selects the display content of the
rstlinefordisplayunit.Thesizeofthecharacters
which are displayed will depend on the selections
made for B41/H11:DisplaySelect2 and B42/H12:
Display Select3 as described below. (For more
details, read Chapter 5.)
CAUTION
It is not possible to set Display Select1 to “Off.”
[B41: Display Select2] Setting of the second line
for display unit
→ This setting is linked with that of parameter H11.
This parameter selects the display content of the
second line for display unit. When “Off” is selected,
one-line display will be adopted regardless of the
setting made for B42/H12:DisplaySelect3.
[B42: Display Select3] Setting of the third line for
display unit
→ This setting is linked with that of parameter H12.
This parameter selects the display content of the
third line for display unit. When “Off” is selected for
this parameter, two-line display is adopted.
[B50: Auto Zero Exe] Execution of the automatic
zero adjustment function
→ This setting is linked with that of parameter M10.
This parameter executes the automatic zero
adjustment function: If “Execution” is selected,
this function will be started. “Now Auto Zero
Executing...” is indicated while the Auto Zero
function is being carried out. The result of the
automaticzeroadjustmentisconrmedusingM12,
M13, and M14. If the result exceeds the rated value,
the warning 82: Auto Zero Wng will be displayed.
(Read Chapter 9.)
Setting Function
No Execution No execution
Execution Automatic zero adjustment is started.
The current output becomes 10.4mA during
this execution (450 seconds).
