YOKOGAWA ADMAG AXR User Manual

<6. PARAMETER DESCRIPTION>
6-45
IM 01E30D01-01EN
Setting Alarm (Device is normal but errors have been made in the setting of parameters.)
Displayunit/BRAIN
(60) alarm content
Alarm countermeasure
message on display unit
NE-107
status
Alarm description Countermeasure
50:Span > 10m/s Check parameter
C40,C41,C42,F20, and F21
S Spanowvelocitysettingsis11
m/s or more
Check whether parameters C40,
C41 and C42 are correct. In case
that multiple range or forward
andreverseowmeasurement
functions is used, check whether
parameters F20 and F21 are
correct.
51:Span < 0.3m/s Check parameter
C40,C41,C42,F20, and F21
S Spanowvelocitysettingis0.25
m/s or less
52:TTL>10000p/s Check parameter D10
and D11
S Totalization rate is 11000 pps or
more
Check whether parameters D10
and D11 are correct.
53:TTL<0.0001p/s Check parameter D10
and D11
S Totalization rate is 0.00005 pps or
less
54:4-20 Lmt Err Check parameter J11
and J12
S The condition [4-20 low limit (J11) <
4-20highlimit(J12)]isnotsatised.
Check whether parameters J11
and J12 are correct.
55:Multi Rng Err Check parameter C42
and F20
S The condition [No. 1 range < No. 2
range]isnotsatisedformultiple
ranges.
Check whether parameters C42
and F20 are correct.
56:H/L Set Err Check parameter G10,
G11, and G12
S The condition [High Alarm (G11)
-Low Alarm (G10) >H/L Alarm Hys
(G12)]isnotsatised.
Check whether parameters G10,
G11 and G12 are correct.
57:Dens Set Err Check parameter C40,
C45, and C46
S Mass units have been selected for
Base Flow Unit (C40) but density
is set to 0.
Check whether parameters C40,
C45 and C46 are correct.
60:PLS>10000p/s Check parameter E10,
E11, and E12
S Pulse rate is 11000 pps or more
with 50% duty selection.
Pulse rate is 10000 pps or more
with 0.05 ms selection"
Check whether parameters E10,
E11 and E12 are correct.
61:PLS > 5000p/s Check parameter E10,
E11, and E12
S Pulse rate is 5000 pps or more with
0.1 ms selection.
62:PLS > 1000p/s Check parameter E10,
E11, and E12
S Pulse rate is 1000 pps or more with
0.5 ms selection.
63:PLS > 500p/s Check parameter E10,
E11, and E12
S Pulse rate is 500 pps or more with
1 ms selection.
64:PLS > 25p/s Check parameter E10,
E11, and E12
S Pulse rate is 25 pps or more with 20
ms selection.
65:PLS > 15p/s Check parameter E10,
E11, and E12
S Pulse rate is 15 pps or more with 33
ms selection.
66:PLS > 10p/s Check parameter E10,
E11, and E12
S Pulse rate is 10 pps or more with 50
ms selection.
67:PLS > 5p/s Check parameter E10,
E11, and E12
S Pulse rate is 5 pps or more with 100
ms selection.
68:PLS > 2.5p/s Check parameter E10,
E11, and E12
S Pulse rate is 2.5 pps or more with
200 ms selection.
69:PLS > 1.5p/s Check parameter E10,
E11, and E12
S Pulse rate is 1.5 pps or more with
333 ms selection.
70:PLS > 1.0p/s Check parameter E10,
E11, and E12
S Pulse rate is 1.0 pps or more with
500 ms selection.
71:PLS > 0.5p/s Check parameter E10,
E11, and E12
S Pulse rate is 0.5 pps or more with
1000 ms selection.
72:PLS > 0.25p/s Check parameter E10,
E11, and E12
S Pulse rate is 0.25 pps or more with
2000 ms selection.
73:PLS<0.0001p/s Check parameter E10,
E11, and E12
S Pulse rate is 0.00005 pps or less.
74: Size Set Err Check parameter C30
and C31
C A value of 3000.1 mm or more is
set for Nominal Size (C31).
Check whether parameters C30
and C31 are correct.
75: Adh Set Err Check parameter K13
to K16
C The condition in Adhesion detection
level, Level:1<Level:2<Level:3<
Level:4isnotsatised.
Check whether parameters K13,
K14, K15 and K16 are correct.
