7-70
IM AQ6370D-01EN
Setting the Table Data Display Mode
1.
Press ADVANCE and then the DATA LOGGING soft key. The soft key menu for
data logging appears.
2.
Press the SETUP soft key. A menu for setting the data logging conditions appears.
3.
Press the TABLE SETTING soft key. The table data display method setting menu
appears.
4.
Press the TABLE MODE CURR/SUMM soft key. The display mode changes to
CURR (displays current values) or SUMM (summary display: MAX, MIN, MAX/
MIN).
5.
If you select summary display in step 4, press the SUMMARY TYPE MAXMIN/
AVG soft key. The items shown in the summary display switches to maximum/
minimum values or average/standard deviation values.
7.15 Analysis Data Logging
