8-12
IM AQ6370D-01EN
Saving the Data Temporarily Saved to Internal Memory
Selecting the Method of Automatically Setting the File Name
Select the method of automatically setting the file name by referring to page 8-6.
Setting the Type of the File to Be Saved to MEMORY
1.
Press FILE.
2.
Press the ITEM SELECT soft key. The soft key menu switches.
3.
Press the MEMORY soft key. MEMORY is selected, and the screen returns to the
previous stage.
4.
Press the WRITE soft key. The memory list and file list are displayed.
Memory list
File list
Selecting the Save Destination and Data Format
5.
Press the MEMORY soft key and specify a save destination of INT (internal
memory) or EXT (USB storage medium).
6.
Press the FILE TYPE soft key and specify a data format of BIN (binary) or CSV
(ASCII format).
8.3 Saving/Loading Displayed Data
