Zebra DS457 User Manual

Imager Preferences 7 - 9
Presentation Mode Field of View
Parameter # 609 (SSI # F1h 61h)
In Presentation Mode, by default the imager searches for a bar code in a smaller region around the aiming
pattern’s center cross to speed search time.
To use a full field of view, scan Presentation Mode Full Field of View. This allows the imager to search the
larger area of the aiming pattern.
*Presentation Mode Default Field of View
(1)
Presentation Mode Full Field of View
(2)

Zebra DS457 Specifications

General

Type	Fixed bar code reader
Wavelength	655 nm
Sensor type	-
Scanner type	1D/2D
Optical sensor resolution	752 pixels
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	450 mA
Safety	ETL, VDE, CETL, EN60950, Ctick, VCCI
Certification	FCC, RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Cables included	USB, VGA
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	58.4 mm
Width	62 mm
Height	29.2 mm
Weight	111 g
