12 - 96 DS457 Fixed Mount Imager Integration Guide
Macro PDF Features
Macro PDF is a special feature for concatenating multiple PDF symbols into one file. The imager can decode
symbols that are encoded with this feature, and can store more than 64 kb of decoded data stored in up to 50
Macro PDF symbols.
Macro PDF User Indications
In this mode the imager provides the following feedback.
CAUTION When printing, keep each Macro PDF sequence separate, as each sequence has unique identifiers.
Do not mix bar codes from several Macro PDF sequences, even if they encode the same data. When
scanning Macro PDF sequences, scan the entire Macro PDF sequence without interruption.
Table 12-2
Macro PDF User Indications
User Scans
Passthrough All
Symbols
Transmit Any
Symbol in Set
Buffer All
Symbols
Beep T Beep T Beep T
Last Macro PDF in set Decode Beep Y Decode Beep Y Decode Beep Y
Any Macro PDF in set except last Decode Beep Y Decode Beep Y 2 Short Low N
Macro PDF is not in current set Decode Beep Y 2 Long Low N 2 Long Low N
Invalid formatted Macro PDF Decode Beep Y 2 Long Low N 2 Long Low N
Macro PDF from a set has already been
scanned
Decode Beep Y 4 Long Low N 4 Long Low N
Out of Macro PDF memory N/A - 3 Long Low N 3 Long Low N
Any non-Macro PDF scanned during a set N/A - 4 Long Low N 4 Long Low N
Flush Macro PDF Low Hi N 5 Long Low N 5 Long Low Y
Abort Macro PDF High Low
High Low
N High Low
High Low
N High Low
High Low
N
Notes:
1. The beep only sounds if the *BEEPER_ON signal is connected.
2. The column marked T indicates whether the symbol is transmitted to the host.
N = No transmission.
