Zebra DS457 User Manual

Symbologies 12 - 31
ISBT Concatenation
Parameter # 577 (SSI # F1h 41h)
Select an option for concatenating pairs of ISBT code types:
• If you select Disable ISBT Concatenation, the imager does not concatenate pairs of ISBT codes it
encounters.
• If you select Enable ISBT Concatenation, there must be two ISBT codes in order for the imager to
decode and perform concatenation. The imager does not decode single ISBT symbols.
• If you select Autodiscriminate ISBT Concatenation, the imager decodes and concatenates pairs of
ISBT codes immediately. If only a single ISBT symbol is present, the imager must decode the symbol the
number of times set via ISBT Concatenation Redundancy on page 12-32 before transmitting its data to
confirm that there is no additional ISBT symbol.
*Disable ISBT Concatenation
(0)
Enable ISBT Concatenation
(1)
Autodiscriminate ISBT Concatenation
(2)

Zebra DS457 Specifications

General

Type	Fixed bar code reader
Wavelength	655 nm
Sensor type	-
Scanner type	1D/2D
Optical sensor resolution	752 pixels
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	450 mA
Safety	ETL, VDE, CETL, EN60950, Ctick, VCCI
Certification	FCC, RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Cables included	USB, VGA
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	58.4 mm
Width	62 mm
Height	29.2 mm
Weight	111 g
