11 - 10 DS457 Fixed Mount Imager Integration Guide
Enable/Disable US Currency Serial Number
Parameter # 683 (SSI # F1 ABh)
To enable or disable US Currency Serial Number, scan one of the following bar codes.
OCR Orientation
Parameter # 687 (SSI # F1 AFh)
Select one of five options to specify the orientation of an OCR string to be read:
• 0
o
to the imaging engine (default)
• 270
o
clockwise (or 90
o
counterclockwise) to the imaging engine
• 180
o
(upside down) to the imaging engine
• 90
o
clockwise to the imaging engine
• Omnidirectional
Setting an incorrect orientation can cause misdecodes.
Enable US Currency
(1)
*Disable US Currency
(0)

Zebra DS457 Specifications

General

Type	Fixed bar code reader
Wavelength	655 nm
Sensor type	-
Scanner type	1D/2D
Optical sensor resolution	752 pixels
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	450 mA
Safety	ETL, VDE, CETL, EN60950, Ctick, VCCI
Certification	FCC, RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Cables included	USB, VGA
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	58.4 mm
Width	62 mm
Height	29.2 mm
Weight	111 g
