Zebra DS457 User Manual

7 - 24 DS457 Fixed Mount Imager Integration Guide
Image Edge Sharpening
Parameter # 664 (SSI # F1h 98h)
This feature uses an edge sharpening technique, and only applies if you set the Image Enhancement
parameter to User. To set this parameter, scan the Image Edge Sharpening bar code, followed by three
numeric bar codes in Appendix D, Numeric Bar Codes that represent the image edge sharpening value.
Alternatively, to set a recommended value, scan one of the value bar codes below.
Recommended settings are:
• Off (0)
• Low (30) - Default
• Med (75)
• High (100).
Image Edge Sharpening
Off
(0)
*Low
(30)
Medium
(75)
High
(100)

Zebra DS457 Specifications

General

Type	Fixed bar code reader
Wavelength	655 nm
Sensor type	-
Scanner type	1D/2D
Optical sensor resolution	752 pixels
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	450 mA
Safety	ETL, VDE, CETL, EN60950, Ctick, VCCI
Certification	FCC, RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Cables included	USB, VGA
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	58.4 mm
Width	62 mm
Height	29.2 mm
Weight	111 g
