Zebra DS457 - Composite TLC-39

To Next Page

To Previous Page

12 - 80 DS457 Fixed Mount Imager Integration Guide

Composite TLC-39

Parameter # 371 (SSI # F0h 73h)

Scan a bar code below to enable or disable Composite bar codes of type TLC-39.

Enable TLC39

(1)

*Disable TLC39

(0)
