8 - 18 DS457 Fixed Mount Imager Integration Guide
Event Reporting
The host can request the imager to provide certain information (events) relative to the imager’s behavior.
Enable or disable the events listed in Table 8-4 and on the following pages by scanning the appropriate bar
codes.
Decode Event
Parameter # 256 (SSI # F0h, 00h)
When enabled, the imager generates a message to the host upon a successful bar code decode. When
disabled, no notification is sent.
Table 8-4 Event Codes
Event Class Event Code Reported
Decode Event Non parameter decode 0x01
Boot Up Event System power-up 0x03
Parameter Event Parameter entry error
Parameter stored
Defaults set (and parameter event is
enabled by default)
Number expected
0x07
0x08
0x0A
0x0F
Enable Decode Event
(1)
*Disable Decode Event
(0)

Zebra DS457 Specifications

General

Type	Fixed bar code reader
Wavelength	655 nm
Sensor type	-
Scanner type	1D/2D
Optical sensor resolution	752 pixels
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	450 mA
Safety	ETL, VDE, CETL, EN60950, Ctick, VCCI
Certification	FCC, RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Cables included	USB, VGA
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	58.4 mm
Width	62 mm
Height	29.2 mm
Weight	111 g
