Imager Preferences 7 - 29

Signature Capture File Format Selector

Parameter # 313 (SSI # F0h 39h)

Select a signature file format appropriate for the system (BMP, TIFF, or JPEG). The imager stores captured

signatures in the selected format.

BMP Signature Format

(3)

*JPEG Signature Format

(1)

TIFF Signature Format

(4)
