3 - 4 DS457 Fixed Mount Imager Integration Guide
Beeper and Decode LED Indications
Table 3-1 provides beeper and LED indications related to certain events. The LED illuminates red to indicate
that the imager has power. SSI events are also listed.
Table 3-1 User Interface Indications
Description
Indication
SSI Event
Beeper Power/Decode LED
Trigger pull No sound Red TRIGGER_PULLED
No decode NODECODE_MSG
Wakeup WAKEUP
Video is off VIDEO_OFF
Video is on VIDEO_ON
Decode Middle Tone Flash of green DECODE
Snapshot started Low Tone Blinking green SNAPSHOT_START
Snapshot is complete Low Tone Red SNAPSHOT_COMPLETE
Bootup Low Tone, Middle
Tone, High Tone
Red BOOTUP
Transmission error Four Low Tones Red TRANSMIT_ERROR
Entry error Low Tone, High Tone Flash of green ENTRY_ERROR
Defaults set High Tone, Low Tone,
High Tone, Low Tone
Flash of green DEFAULTS_SET
Parameter entered PARAM_ENTERED
Number entry expected High Tone, Low Tone Flash of green NUMBER_EXPECTED

Zebra DS457 Specifications

General

Type	Fixed bar code reader
Wavelength	655 nm
Sensor type	-
Scanner type	1D/2D
Optical sensor resolution	752 pixels
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	450 mA
Safety	ETL, VDE, CETL, EN60950, Ctick, VCCI
Certification	FCC, RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Cables included	USB, VGA
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	58.4 mm
Width	62 mm
Height	29.2 mm
Weight	111 g
