12 - 68 DS457 Fixed Mount Imager Integration Guide

Postal Codes

US Postnet

Parameter # 89 (SSI # 59h)

To enable or disable US Postnet, scan the appropriate bar code below.

US Planet

Parameter # 90 (SSI # 5Ah)

To enable or disable US Planet, scan the appropriate bar code below.

Enable US Postnet

(1)

*Disable US Postnet

(0)

Enable US Planet

(1)

*Disable US Planet

(0)
