Zebra DS457 User Manual

User Preferences 6 - 21
Unique Bar Code Reporting
Parameter # 723 (SSI # F1h D3h)
Enable this to report only unique bar codes while the trigger is pressed. This option only applies when
Continuous Bar Code Read is enabled.
Mirrored Image
Parameter # 624 (SSI # F1h 70h)
Enable this to scan images in reverse, or mirrored, as if seen through a mirror. This mode is useful in
applications requiring scanning through a mirror and using symbologies that do not decode in reverse.
Enabling this mode when using snapshot, video, or video viewfinder modes transmits images as mirrored
images.
Disable Unique Bar Code Reporting
(0)
*Enable Unique Bar Code Reporting
(1)
*Disable Mirrored Image
(0)
Enable Mirrored Image
(1)

Zebra DS457 Specifications

General

Type	Fixed bar code reader
Wavelength	655 nm
Sensor type	-
Scanner type	1D/2D
Optical sensor resolution	752 pixels
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	450 mA
Safety	ETL, VDE, CETL, EN60950, Ctick, VCCI
Certification	FCC, RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Cables included	USB, VGA
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	58.4 mm
Width	62 mm
Height	29.2 mm
Weight	111 g
