13 - 2 DS457 Fixed Mount Imager Integration Guide
Parsing Driver’s License Data Fields (Embedded Driver's License Parsing)
To begin programming a parsing rule:
1. Scan Begin New Driver’s License Parse Rule on page 13-3.
2. Scan any of the field bar codes on the following pages, or Send Keystroke (Control Characters and
Keyboard Characters) on page 13-23 to complete the parsing rule.
3. After entering the entire rule, scan Save Driver’s License Parse Rule on page 13-3 to save the rule.
To abort the programming sequence at any time during programming, scan Quit Entering Driver’s License Rule
on page 13-3. Any previously saved rule is retained.
To erase a programmed saved rule, scan Erase Driver’s License Parse Rules on page 13-3.
Embedded Driver's License Parsing Criteria - Code Type
After specifying the fields and their order for the parsed driver's license, you can also apply standard ADF rules
to the parsed data using the
Parsed Driver’s License criterion bar code in the Advanced Data Formatting
Programmer Guide.
See Embedded Driver's License Parsing ADF Example on page 13-20 for a sample ADF rule using this code
type criterion.
NOTE Only ONE driver’s license parsing rule may be stored in memory at any time. Saving a new rule replaces
the prior rule.
NOTE Only create standard ADF rules on parsed driver's license data when configured for Embedded Driver's
License Parsing.

Zebra DS457 Specifications

General

Type	Fixed bar code reader
Wavelength	655 nm
Sensor type	-
Scanner type	1D/2D
Optical sensor resolution	752 pixels
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	450 mA
Safety	ETL, VDE, CETL, EN60950, Ctick, VCCI
Certification	FCC, RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Cables included	USB, VGA
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	58.4 mm
Width	62 mm
Height	29.2 mm
Weight	111 g
