CHAPTER 2 INSTALLATION

Overview

This chapter provides information on unpacking, mounting, and installing the imager.

Unpacking

Remove the DS457 from its packing and inspect for damage. If the imager is damaged, call Zebra Global

Customer Support on page xviii.

KEEP THE PACKING. It is the approved shipping container and should be used if the equipment needs to be

returned for servicing.
