2 - 16 DS457 Fixed Mount Imager Integration Guide
Accessories
Zebra offers the following accessories for the imager. Refer to Solution Builder (ordering guide).
Table 2-5
DS457 Imager Accessories
Accessory Part Number
Power Supplies (RS-232)*
5 VDC 850 mA; US, Canada, Mexico, Japan, Taiwan PWRS-14000-253R
5 VDC 850 mA; EU, UK, EMEA, Russia, South Africa PWRS-14000-256R
5 VDC 850 mA; China PWRS-14000-257R
5 VDC 850 mA; Australia, Hong Kong, New Zealand PWRS-14000-258R
5 VDC 850 mA; Argentina, Uruguay PWRS-14000-259R
RS-232
9-Pin female (DB9) with straight connector, 6 ft, with trigger jack, no beeper 25-13227-03R
9-Pin female (DB9) with straight connector, 6 ft, with trigger jack and beeper 25-13228-03R
9-Pin female (DB9) with straight connector, 6 ft, no trigger jack or beeper 25-58918-02R
9-Pin female (DB9) coiled, 9 ft, no trigger jack or beeper 25-58918-03R
9-Pin female (DB9) with straight connector, 6 ft, with trigger jack and no hardware
handshaking
25-63736-02R
TTL RS-232 to true RS-232 conversion cable, low profile connector 25-62186-03R
USB
9-Pin female (DB9) with straight connector, 6 ft, with trigger jack and beeper 25-58925-02R
9-Pin female (DB9) with straight connector, 6 ft, no trigger jack or beeper 25-58926-04R
9-Pin female (DB9), 18 in, no trigger jack or beeper (for kiosks) 25-58926-05R
9-Pin female (DB9), coiled, 9 ft, no trigger jack or beeper 25-58926-06R
Optional Accessories
Push button trigger cable 25-04950-01R
Photo sensor trigger cable (retroreflective, IR 850nm, 7 foot range) 25-13176-01R
Gooseneck stand (twilight black) 20-60136-02R
POS wall/counter mount
KT-145344-01
MS320x to DS457 conversion mounting bracket
KT-152342-01
*Standalone power supply is not used for USB hosts.
