Zebra DS457 User Manual

OCR Reading 11 - 19
Digit or Fill (8)
The data validator accepts any numeric or fill character in this position.
Template Valid data Valid data Invalid data
88899 12345 >>789 <<789
Alpha or Fill (F)
The data validator accepts any alpha or fill character in this position.
Template Valid data Valid data Invalid data
AAAFF ABCXY LMN>> ABC<5
Required Space ( )
When this option appears in the template string, the template accepts a space if present. Optional characters
are not allowed as the first character(s) in a field of like characters.
Template Valid data Invalid data
99 99 12 34 67891
8
F
Space

Zebra DS457 Specifications

General

Type	Fixed bar code reader
Wavelength	655 nm
Sensor type	-
Scanner type	1D/2D
Optical sensor resolution	752 pixels
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	450 mA
Safety	ETL, VDE, CETL, EN60950, Ctick, VCCI
Certification	FCC, RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Cables included	USB, VGA
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	58.4 mm
Width	62 mm
Height	29.2 mm
Weight	111 g
