Zebra DS457 User Manual

4 - 12 DS457 Fixed Mount Imager Integration Guide
40 mil
QR Code
3.0 in
7.62 cm
10.4 in
26.42 cm
N/A N/A
4.0 mil
PDF417
1.4 in
3.56 cm
3.8 in
9.65 cm
1.6 in
4.06 cm
2.7 in
6.86 cm
6.67 mil
PDF417
1.0 in
2.54 cm
4.8 in
12.19 cm
1.1 in
2.79 cm
3.6 in
9.14 cm
Table 4-4 DS457-HD/DP Decode Distances (Presentation Mode with No Motion Enhancement) (Continued)
Symbol Density/
Bar Code Type
Typical Working Ranges
Guaranteed Working
Ranges
Near Far Near Far
Notes:
1. Near distances are FOV limited.
2. Contrast is measured as Mean Reflective Difference (MRD) at 670 nm.
3. Working range specifications at temperature = 23°C, pitch=18°, roll=0°,
skew=0°, photographic quality, humidity 45-70% RH.
4. Enabling Motion Enhancement reduces decode ranges.

Zebra DS457 Specifications

General

Type	Fixed bar code reader
Wavelength	655 nm
Sensor type	-
Scanner type	1D/2D
Optical sensor resolution	752 pixels
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	450 mA
Safety	ETL, VDE, CETL, EN60950, Ctick, VCCI
Certification	FCC, RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Cables included	USB, VGA
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	58.4 mm
Width	62 mm
Height	29.2 mm
Weight	111 g
