6 - 4 DS457 Fixed Mount Imager Integration Guide
PDF Prioritization Timeout 720 F1h D0h 400 ms 6-23
Multicode Mode 677 F1h A5h Disable 6-24
Multicode Expression 661 F1h 95h 1 6-25
Multicode Mode Concatenation 717 F1h, CDh Disable 6-33
Multicode Concatenation Symbology 722 F1h, D2h Concatenate as
PDF417
6-34
Miscellaneous Parameters
Transmit Code ID Character 45 2Dh None 6-37
SSI Prefix Value 105 69h <CR> 6-38
SSI Suffix 1 Value
SSI Suffix 2 Value
104
106
68h
6Ah
<CR>
<CR>
6-38
Non-SSI Prefix Value 99, 105 63h, 69h <CR><LF> 6-38
Non-SSI Suffix 1 Value
Non-SSI Suffix 2 Value
98, 104
100, 106
62h, 68h
64h, 6Ah
<CR><LF>
<CR><LF>
6-38
Scan Data Transmission Format 235 EBh Data as is 6-39
FN1 Substitution Values 103, 109 67h, 6Dh Set 6-40
Transmit “No Read” Message 94 5Eh Disable 6-41
Report Version 6-41
Table 6-1 User Preferences Default Table
Parameter
Parameter
Number
SSI
Number
Default
Page
Number

Zebra DS457 Specifications

General

Type	Fixed bar code reader
Wavelength	655 nm
Sensor type	-
Scanner type	1D/2D
Optical sensor resolution	752 pixels
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	450 mA
Safety	ETL, VDE, CETL, EN60950, Ctick, VCCI
Certification	FCC, RoHS
Product color	Black
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Cables included	USB, VGA
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	58.4 mm
Width	62 mm
Height	29.2 mm
Weight	111 g
