Zebra MC33 Series User Manual

Data Capture
120
Figure 106 Aiming Pattern
Figure 107 Pick List Mode with Multiple barcodes in Aiming Pattern
4. The captured data appears in the text field.
Barcode Capture with DS3678 Bluetooth Scanner
Pair the DS3678 with the MC33XX. See Pairing the DS3678 Digital Scanner on page 125 for more information.
1. Ensure that an application is open on the device and a text field is in focus (text cursor in text field).
2. Point the DS3678 at a barcode.
Figure 108 Barcode Scanning with DS3678 (-SR shown)
3. Press and hold the trigger.
Ensure the barcode is within the area formed by the aiming pattern. The aiming dot is used for increased
visibility in bright lighting conditions.

Zebra MC33 Series Specifications

General

Connectivity	USB 2.0, Bluetooth
Touch Panel	Capacitive, glove and wet touch support
Keypad Options	Touchscreen or physical keypad
Scanning	1D/2D barcode scanning
Wireless LAN	IEEE 802.11 a/b/g/n/ac
Operating Temperature	-20° C to 50° C
