Accessories
170
MC33XX-R Rubber Boot
The rubber boot provides additional protection to the MC33XX-R. The rubber boot is comprised of two pieces; one
for the mobile computer and one for the turret cup.
To attach the rubber boot:
1. Insert the rubber boot for the turret cup into the rubber boot for the mobile computer, to form a single piece, if it
is not already attached.
Figure 30 Two Piece Rubber Boot
2. Slide the top of the MC33XX-R into the top of the rubber boot.
Figure 31 Attach Top of Rubber Boot
3. Grasp the bottom of the rubber boot and place over the bottom of the MC33XX-R.
