Zebra MC33 Series User Manual

Applications
98
Diagnostic Tool
The Diagnostic Tool is a utility that determines the health of the MC33XX. Use the Diagnostic Tool to troubleshoot
the device and determine issues.
1. Swipe up from the bottom of the Home screen and touch .
Figure 77 Diagnostic Tool
2. Touch Run Test. The app tests all enabled subsystems (by default only the Battery and System tests are
enabled). See Settings on page 100 to enable subsystem tests.
Figure 78 Test Passed Screen

Zebra MC33 Series Specifications

General

Connectivity	USB 2.0, Bluetooth
Touch Panel	Capacitive, glove and wet touch support
Keypad Options	Touchscreen or physical keypad
Scanning	1D/2D barcode scanning
Wireless LAN	IEEE 802.11 a/b/g/n/ac
Operating Temperature	-20° C to 50° C
