Zebra MC33 Series - Lanyard; Install Lanyard on MC33 XX

Accessories
191
Lanyard
The lanyard is an optional accessory for holding the MC33XX and is comprised of multiple pieces. The lanyard can
be worn using the cross-body strap, or it can be worn on the belt, after removing the cross-body strap.
Figure 61 Lanyard
Install Lanyard on MC33XX
To install the lanyard on the MC33XX:
1. Thread the tab of the Device to Retractor Interface through the slot at the bottom of the MC33XX.
Device to Retractor
Int erfac e
Quick Release Button
Lanyard Cord
Retractor
Belt Clip
Retractor to Strap
Int erfac e
Cross-body Strap
Strap Extender
Shoulder Pad
